Our power plants can be found in nearly 50 countries around the world. A low-head Kaplan turbine on a calm river in the North of England, a compact solution for a remote location in the Nepalese Himalayas or an elegant Pelton turbine for a power plant in South Africa. CINK machines help produce renewable energy in power plants from Chile to Japan.
490 kW of installed power
37,6 m of hydraulic head
1 600 l/s of design flow
One 2-cell Crossflow turbine
1 531 kW of installed power
33 m of hydraulic head
5 650 l/s of design flow
One 2-cell Crossflow turbine
165 kW of installed power
1,7 m of hydraulic head
11 300 l/s of design flow
One horizontal Kaplan turbine
144 kW of installed power
15,3 m of hydraulic head
1 200 l/s of design flow
Power Box + Crossflow turbine
1 496 kW of installed power
48,4 m of hydraulic head
3 750 l/s of design flow
One 2-cell Crossflow turbine
Pt (kW): 3657 / 3657 / 3613 / 1330
H (m): 414 / 414 / 409 / 215
Q (l/s): 1000 / 1000 / 1000 / 700
Four horizontal Pelton turbines
1 613 kW of installed power
141 m of hydraulic head
1 300 l/s of design flow
One vertical 5-jet Pelton turbine
557 kW of installed power
3,22 m of hydraulic head
20 000 l/s of design flow
One horizontal Kaplan turbine
287 kW of installed power
186 m of hydraulic head
1 300 l/s of design flow
One horizontal 2-jet Pelton turbine
2 x 6 517 kW of installed power
369 m of hydraulic head
2 x 2 000 l/s of design flow
Two vertical 5-jet Pelton turbines
200 kW of installed power
7 m of hydraulic head
3 600 l/s of design flow
One 2-cell Crossflow turbine
2 x 4 002 kW of installed power
59 m of hydraulic head
2 x 8 000 l/s of design flow
Two 2-cell Crossflow turbines
